Clampon wear sleeve construction

  • Cost Effective
  • Light weight
  • Totally enclosed spindle
  • Rubber sleeves available in a wide range of polymers
  • Maintenance friendly
  • Field replaceable sleeve
  • Same face to face dimension as diaphragm valves
  • Standard pressure rating from 1600 kPa - 2500 kPa
Size range - 25mm TO 500mm Larger Sizes and Higher Working Pressures on request Standard finish - Powder Coat Electroplating, Galvanising or other finishes on Request

Click Here to Download CLAMPON Slurry Pinch Valve PDF

TECHNICAL SPECIFICATIONS

PROPERTIES VALUES
MATERIAL BASIS Natural rubber (92%)
SURFACE FINISH Wrap cure finish
HARDNESS 37 SHORE
COLOUR Pink
TENSILE STRENGTH 25.0 Mpa (min)
SPECIFIC GRAVITY 0.99 ± 0.02
ELONGATION @ BREAK 800% (min)
TEAR STRENGTH 40 kg/cm
OZONE RESISTANCE Fair
TEMPERATURE RANGE Recommended max 70ºC
General properties and applications SupaLine® Red is a high quality natural rubber compound suitable for extreme wet abrasion. Clampon wear sleeve construction Clampon wear sleeves are hand built and are comprised of a SupaLine Red wear liner made to the required thickness, and are thereafter wrapped in a specific pattern with 1mm aperture rubber encased nylon strands to maximise durability and strength. Wrapped reinforcing material is highly ozone resistant. This construction method prevents the sleeves from memory build up which can result in the sleeves becoming oval.
